Thermo-Hygrostat
Cooling Facilities
Print
temperature-img
Specifications
  • Retention amount
Supercomputer room UPS room Battery room Electric room
30RT 23EA 20RT 9EA 15RT 2EA
20RT 2EA		 15RT 3EA
20RT 2EA
※ 1 RT(ton of refrigeration) is the removal of heat required to freeze a metric ton (i.e., 1000 kg) of water at 0 °C to ice at 0°C over a 24 hour period. 1RT = 3,024Kcal
Purpose
  • It maintains constant temperature and humidity in the supercomputer room
Features
  • The best clean system uses HEPA filter, which can remove fine particulate dust
  • It can maximizes cooling efficiency by adopting the top- down air sending method
temperature-img
Specifications
  • Retention amount
Turbo refrigerator Cooling tower Air Conditioner Thermal Storage tank
500RT x 4EA
650RT x 2EA		 600RT x 4EA
720RT x 2EA		 8,500㎥/h x 2EA 330Ton
160Ton
※ 1 RT(ton of refrigeration) is the removal of heat required to freeze a metric ton (i.e., 1000 kg) of water at 0 °C to ice at 0°C over a 24 hour period. 1RT = 3,024Kcal
Purpose
  • It cools the heat from the operating supercomputer, makes water at 5°C, and supplies the super computer and the whole building with the cooling water.
Features
  • It economizes energy cost by using the thermal storage tank
  • Using the closed cooling tower, it can be operated all the year round.
